Stereo Power Amplifier
Click here for a larger image

Back View
Click here for a larger image

The Ultimate Stereo Power Amplifier

This amplifier gives you the power and versatility you need to create a professional sound system. Its wide frequency response makes it suitable for amplifying any type of audio including music or vocals. It can be used in meeting halls, restaurants, schools, stores, and at home –the perfect solution for paging systems anywhere. Get the power you need with 2 x 75 Watt to handle all your audio needs.

110/220 Voltage Selector

This amplifier has selectable input voltage from 110 V/60 Hz (the standard in USA and Canada) to 220 V/50 Hz (for European operation). Please make sure the switch is in the proper position before operating.

Compatibility

Compatible with CD players, walkmans, and computerized devices, including MP3s, via 3.5 millimeter to RCA converter.

RCA L/R Line Input

Lets you connect the desired line input source.

Take Control

Use the control center panel located on the face of the unit to make adjustments to microphone volume, master volume, balance, bass, and treble.

Push Type Speaker Terminals

Lets you easily connect speaker wires directly to the amplifier.

Replaceable Power Fuse

The amplifier uses a fuse for protection against surges and short circuit. If the amplifier suddenly turns off and will not turn on, check the fuse and replace it if necessary. (Replacement fuse to use: 1.5-amp, 250-volt, fast-acting 5 x 20 millimeter fuse –not included)

Additional Features

• Harmonic Distortion: 0.3%
• 2 x 75 Watt RMS at 4 Ohm
• Blue LED Output Level Display
• Frequency Response: 20 Hz-40 kHz
• Power Fuse: 1.5 A, 250V Fast-Acting (5 x 20 millimeter)
• Power Requirement: 120 V AC 50 Hz/230 V AC 50 Hz
• Tone Controls: Bass and Treble: +/-10dB (100 Hz/10 kHz)
• Dimensions: 8.27 x 2.72 x 5.39 inch (190 x 70 x 137 millimeter)

This Pyle Pro 1000-watt receiver has a built in DVD player, USB drive, and auxiliary RCA input. In other words, it can handle almost anything you throw at it–your favorite movies, the video clips you store on your USB drive, or your favorite music on your iPod. Each input has its own gain control. The digital colorful fluorescent display shows relevant track and disc information in addition to proving a power level dB display. This unit is also equipped with an AM/FM tuner with up to 60 presets. The PD1000A powers up to 4 speakers, and has RGB, RCA, and S-video outputs as well as a subwoofer line output. It runs on selectable 110V or 220V for easier system integration.

The digital colorful fluorescent display shows relevant track and disc information

Powers 4 Loudspeakers

The PD1000A can power up to four loudspeakers for room-filling sound. Separate gain controls for DVD, Tuner, USB, and MP3 ensure that you get the power you need for the sound and source you want. A subwoofer line audio output gives you added versatility for a bigger sound. A/B audio speaker selectors make it easy to choose between multiple speaker configurations.

Multi Media Disc Formats Compatible

Play virtually any disc on the Pyle PD1000A, including DVDs, CDs, and VCDs. This system also supports user-burned discs including CD-R, CD-RW, and MP4 data discs.

This Pyle Pro 1000-watt receiver has a built in DVD player, USB drive, and auxiliary RCA input

Digital Colorful Fluorescent Display

The colorful front panel features a 1-line flourescent display that displays time, station, and power information. The front panel is illuminated with blue LED lights for and a visual power level DB display for information and makes an attractive addition to any home theater system.

AM/FM Quartz Synthesized Radio Tuner

The quartz-tuned AM/FM radio comes with a 50-station AM/FM memory preset, as well as Auto Station Seek/Store for a simple way to get quick access to all your area’s radio station information.

USB and AUX Inputs for Digital Music

Use the AUX input to connect your digital media players such as iPod, iPhone, or Android music phone and listen to your digital music files over your home stereo system. A USB reader function for use with portable USB drives lets you play your MP3 tunes from a portable flash memoery drive.

Pyle PT510 PA Amplifier w/ MIC Talkover
view larger

Front mounted EQ and Volume Controls and Media Player
view larger

Removable AC Power Cord
view larger

Compact size to fit any shelf
view larger

PT510 (Back)
view larger

PT510 Diagram
view larger

Power Amplifier

The Pyle PT510 240 Watt Power amplifier provides ultimate power and features a 70V output, and USB MP3 Media playback and built-in FM radio. The PT510 works great for public announcements, school auditoriums, office paging systems, and more.

240 Watts/70 Volts of Power

The PT510 amplifier has a 70 volt transformer that can power as many speakers as you desire. You need to make sure that the total power requirement of all the added speakers does not exceed the power output capability of the distribution amplifier.

Smartphone and iPod MP3 Playback

Connect your Smartphone, iPod or other external devices and let it charge through the USB and at the same time play music through the auxiliary input.

USB, SD/MMC Card MP3 Playback

Quickly transfer music from your computers Media library to USB flash drive or SD memory card. Then plug in your USB Thumb drive or SD/MMC memory card and play your favorite music.

Microphone Talkover

Simply talk into MIC1’s input and the music volume will automatically lower when spoken into so the announcement can be heard loud and clear. This public address function is great for schools, offices, paging systems, public announcements and just about any large social event.

Built-in FM Radio

The PT510 comes with a built-in FM radio with auto scan function. Play your favorite FM radio stations for your music enjoyment with help from the LED display. Retractable antenna mounted on the back for better signal reception. Use Auto scan function to find your favorite radio stations.

Dual Microphones

The PT510 comes with two microphone inputs. MIC1 features a “Talk over Feature”. You can use it to broadcast your message or sing over the streaming audio or background music. Both microphone inputs have independent volume controls.

Customize your sound

You will be able to control the way your music sounds by adjusting the equalizer settings including lows, mids, highs, master volume and independent input volume controls. All of these controls are conveniently located on the front of the unit.

Worldwide Use

This amplifier has selectable input voltage from 110 V/60 Hz (the standard in USA and Canada) to 220 V/50 Hz (for European operation). Please make sure the switch is in the proper position before operating.

Included accessories:

Removable AC Power Cord

Features

• Built-in USB/SD Card Readers
• FM Tuner with EQ/Volume Control
• Media Mode Selector Function
• 4Ohm/8Ohm – 70 Volt/100 Volt Speaker Outputs Terminals
• Tuner Down/Up/Scan Button Functions
• Power On/Off with Red LED Indicator
• Master Volume Rotary Control
• High/Mid/Low Tone Level Controls
• Front 3.5mm AUX Input Jack for iPod/MP3 Players
• MIC 1 Talk-Over Feature
• Phono/AUX Volume Input Control
• Mic 1/Mic 2 Volume Controls
• Mic 1 /Mic 2/AUX-IN 6.35mm/ ¼” Input Connectors
• AUX-IN RCA Input Jack
• Voltage Selector 110/220V
• Removable AC Power Cord
• Un-Switched AC Power Outlet for Optional Equipment
• Built in Retractable Antenna for FM Tuner
• Dimensions: 12.6” H x 7.48” W x 3.15” D

More Power Amplifier Options:
	PCAU15A	PCAU25A	PCAU35A	PCAU46A	PT510
Total Watt Power	2 x 15 Watt	2 x 40 Watt	2 x 75 Watt	2 x 120 Watt	240 Watt
MP3 Media Player Function	X	X	X	X	X
SD/MMC Card Slots	X	X	X	X	X
AUX/CD Input	X	X	X	X	3.5mm and 1/4″
MIC Input Jack					Dual – 2 Inputs
USB Slot	X	X	X	X	X
Included Remote Control	X	X	X	X	X
Worldwide Use (Voltage Selector)	X	X	X	X	X
70 Volt Speaker Output					X
